DS6130 XITCORP Solid State Drive (M.2 2242 SATA) In Stock
Wide-temperature pSLC industrial M.2 2242 SATA SSD on XT6160, 8-32GB, TBW up to 800TB, 50Grms vibration tolerance, anti-sulfuration, for industrial switches, base stations and network gates.
- Manufacturer
- XITCORP
- Package
- M.2 2242 SATA
- Lifecycle
- PRODUCTION
- Datasheet
- N/A
- Category
- Solid State Drive
- Temp Range
- -40.0°C to 85.0°C
- RoHS
- Compliant
- Lead Time
- 3–7 business days
- Shipping
- DHL Express · Worldwide
What are the key features of DS6130?
- XT6160 RISC-V controller in pSLC mode
- 8/16/32 GB with 380–800 TB TBW
- -40°C to +85°C operating range
- 50 Grms vibration, 1,500 G shock tolerance
- LDPC, E2E, SRAM/DRAM ECC, RAID+
- High-temperature protection, safe start, anti-sulfuration
What is DS6130 used for?
The DS6130 is designed for industrial switches, network security equipment, base stations, gateway routers and industrial network isolation devices — compact datacom systems needing extreme endurance boot storage.
What are the specifications of DS6130?
| Controller | XITCORP XT6160 |
| NAND Flash | YMTC 3D TLC in pSLC mode |
| Interface | SATA 3.0 (6Gb/s) |
| Form Factor | M.2 2242 |
| Capacity Options | 8 GB / 16 GB / 32 GB |
| Sequential Read (max) | 550 MB/s |
| Sequential Write (max) | 450 MB/s |
| Random Read (max) | 40,000 IOPS |
| Random Write (max) | 60,000 IOPS |
| TBW | 380 TB (8 GB) / 400 TB (16 GB) / 800 TB (32 GB) |
| Power Consumption | Active <1.5 W, Idle <1.0 W |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Vibration (non-operating) | 50 Grms, 20–2,000 Hz |
| Shock (non-operating) | 1,500 G at 0.5 ms, 3 axis |
| Key Features | LDPC, E2E, SRAM/DRAM ECC, RAID+, high-temperature protection, safe start, anti-sulfuration |
| OS Compatibility | Windows 7/8.1/10, Linux, Kylin/UOS |
| Package | M.2 2242 SATA |
Compliance & Regulatory
| RoHS Status | Compliant |
Additional Information
| Product Family | Industrial Storage |
What are equivalent replacements for DS6130?
No known alternates. Submit an RFQ and our team can suggest alternatives.
Frequently Asked Questions
How rugged is the DS6130 in temperature and vibration terms?
It operates from -40°C to +85°C and withstands 50 Grms vibration across 20–2,000 Hz plus 1,500 G shock, with anti-sulfuration treatment for corrosive datacom environments.
What endurance does the DS6130's pSLC design achieve?
Running YMTC 3D TLC in pSLC mode yields 380 TB TBW at 8 GB, 400 TB at 16 GB and 800 TB at 32 GB — extreme endurance for boot and log storage.
What interface, speed and power does it provide?
Over SATA 3.0 6Gb/s it reaches 550 MB/s read and 450 MB/s write with 40,000/60,000 random read/write IOPS, drawing under 1.5 W active in M.2 2242.
Which applications is the DS6130 suitable for?
XITCORP designed it for industrial switches, network security equipment, base stations, gateway routers and network isolation devices — compact always-on datacom systems built on the XT6160 RISC-V controller.
